Kepital F25-03 LOF

Produkt anfragen   Datenblatt herunterladen    Telefonische Beratung +49 40 727702-0



<font size="3"><strong>A medium-low viscosity grade for general injection molding. </strong></font>

Low odor grade improved on thermal stability.

Properties Test condition Method Unit Value
Physical Density ISO 1183 g/cm³ 1,41
Physical Melt Flow Rate ISO 1133 g/10min 13
Physical Molding Shrinkage (Flow Direction) t 3mm, Ø 100mm KEP Method % 2
Thermal Heat Deflection Temperature (HDT) 1.8 MPa ISO 75-1,2 ˚C 100
Thermal Flammability UL94 Class HB
Mechanical Tensile Strength 23˚C ISO 527-1,2 MPa 65
Mechanical Flexural Strength 23˚C ISO 178 MPa 90
Mechanical Flexural Modulus 23˚C ISO 178 MPa 2.650
Mechanical Charpy Notched Impact Strength ISO 179/1eA kJ/m² 6
Mechanical Nominal Strain at Break 23˚C ISO 527-1,2 % 33
Electrical Surface Resistivity IEC 60093 Ω 1 x 10^16
Electrical Volume Resistivity IEC 60093 Ω • cm 1 x 10^14
Electrical Dielectric Strength IEC 60243-1 kV /mm 19
