Kepital FG2025 LOF
Produkt anfragen Datenblatt herunterladen Telefonische Beratung +49 40 727702-0
<font size="3">A medium-high viscosity grade for general injection molding. It was reinforced glass fiber, and suitable for parts requiring very high stiffness, fatigue resistance, creep resistance, and heat resistance. Low odor grade improved on heat stability. </font> |
| Properties | Test condition | Method | Unit | Value | |
|---|---|---|---|---|---|
| Physical | Density | ISO 1183 | g/cm³ | 1,59 | |
| Physical | Melt Flow Rate | ISO 1133 | g/10min | 7 | |
| Physical | Molding Shrinkage (Flow Direction) | t 3mm, Ø 100mm | KEP Method | % | 0,5 |
| Thermal | Flammability | UL94 | Class | HB | |
| Mechanical | Tensile Strength | 23˚C | ISO 527-1,2 | MPa | 140 |
| Mechanical | Flexural Strength | 23˚C | ISO 178 | MPa | 190 |
| Mechanical | Flexural Modulus | 23˚C | ISO 178 | MPa | 8.000 |
| Mechanical | Charpy Notched Impact Strength | ISO 179/1eA | kJ/m² | 7 | |
| Mechanical | Tensile Elongation | 23˚C | ISO 527-1,2 | % | 2,5 |
| Electrical | Surface Resistivity | IEC 60093 | Ω | 1 x 10^16 | |
| Electrical | Volume Resistivity | IEC 60093 | Ω • cm | 1 x 10^14 |
