Kepital TE-22 LOF
Produkt anfragen Datenblatt herunterladen Telefonische Beratung +49 40 727702-0
<font size="3">A medium viscosity grade improved on thermal stability, for general injection molding. It was modified </font><font size="3"></font> Low odor grade improved on heat stability with elastomer, and suitable for parts requiring a much higher impact resistance and toughness. |
| Properties | Test condition | Method | Unit | Value | |
|---|---|---|---|---|---|
| Physical | Density | ISO 1183 | g/cm³ | 1,37 | |
| Physical | Melt Flow Rate | ISO 1133 | g/10min | 8,5 | |
| Thermal | Heat Deflection Temperature (HDT) | 1.8 MPa | ISO 75-1,2 | ˚C | 78 |
| Thermal | Heat Deflection Temperature (HDT) | 0.45 MPa | ISO 75 | ˚C | 148 |
| Thermal | Flammability | UL94 | Class | HB | |
| Thermal | Vicat Softening Point | (10N) | ISO 306 | ˚C | 160 |
| Thermal | Vicat Softening Point | (50N) | ISO 306 | ˚C | 134 |
| Mechanical | Tensile Strength | 23˚C | ISO 527-1,2 | MPa | 51 |
| Mechanical | Flexural Strength | 23˚C | ISO 178 | MPa | 68 |
| Mechanical | Flexural Modulus | 23˚C | ISO 178 | MPa | 1.900 |
| Mechanical | Charpy Notched Impact Strength | ISO 179/1eA | kJ/m² | 11 | |
| Mechanical | Nominal Strain at Break | 23˚C | ISO 527-1,2 | % | 40 |
| Mechanical | Tensile Strain at Break | 23˚C | ISO 527-1,2 | % | 70 |
| Electrical | Surface Resistivity | IEC 60093 | Ω | 1x 10^16 | |
| Electrical | Volume Resistivity | IEC 60093 | Ω • cm | 1x 10^14 | |
| Various | Molding Shrinkage (Flow Direction) | t 2mm, Ø 60mm | % | 1,8 |
