Kepital TE-24 LOF
Produkt anfragen Datenblatt herunterladen Telefonische Beratung +49 40 727702-0
<font size="3">A medium viscosity grade improved on thermal stability, for general injection molding. It was modified with elastomer, and suitable for parts requiring a much higher impact resistance and toughness. </font><font size="3"></font> Low odor grade improved on heat stability. |
| Properties | Test condition | Method | Unit | Value | |
|---|---|---|---|---|---|
| Physical | Density | ISO 1183 | g/cm³ | 1,35 | |
| Physical | Melt Flow Rate | ISO 1133 | g/10min | 6 | |
| Physical | Molding Shrinkage (Flow Direction) | t 3mm, Ø 100mm | KEP Method | % | 1,8 |
| Thermal | Flammability | UL94 | Class | HB | |
| Mechanical | Tensile Strength | 23˚C | ISO 527-1,2 | MPa | 41 |
| Mechanical | Flexural Strength | 23˚C | ISO 178 | MPa | 53 |
| Mechanical | Flexural Modulus | 23˚C | ISO 178 | MPa | 1.450 |
| Mechanical | Charpy Notched Impact Strength | ISO 179/1eA | kJ/m² | 13 | |
| Mechanical | Tensile Elongation | 23˚C | ISO 527-1,2 | % | 50 |
| Electrical | Surface Resistivity | IEC 60093 | Ω | 1x 10^16 | |
| Electrical | Volume Resistivity | IEC 60093 | Ω • cm | 1x 10^14 |
