Starex WX-9300UV

Produkt anfragen   Datenblatt herunterladen    Telefonische Beratung +49 40 727702-0

PropertiesTest conditionMethodUnitValue
FlammabilityFlammabilityHBUL94mm1.5, 3.0
ThermalVicat Softening TemperatureB/120ISO R 306°C99
ThermalVicat Softening TemperatureB/50ISO R 306°C96
ThermalHeat Deflection Temperature (unannealed)1.8 MPa, 4.0mmISO 75-2°C77
MechanicalRockwell HardnessR-scaleISO 2039-2-104
MechanicalCharpy Impact Strength (V-notched)23°C, 4mmISO 179 1eAKJ/m²12
MechanicalIzod Impact Strength (notched)at 23°C, 4mmISO 180 1AKJ/m²10
MechanicalFlexural Modulus2mm/minISO 178MPa2250
MechanicalFlexural Strength2mm/minISO 178MPa70
MechanicalTensile Strength at Break50mm/minISO 527MPa39
MechanicalTensile Modulus50mm/minISO 527MPa2100
MechanicalTensile Strain at Break50mm/minISO 527%13
MechanicalTensile Strength at Yield50mm/minISO 527MPa47
PhysicalMold Shrinkage (TD)X-Flow at 3.2mm(TD)ISO 2577%0,4
PhysicalMold Shrinkage (MD)Flow at 3.2mm(MD)ISO 2577%0,37
PhysicalMelt Flow Index220°C, 10kgISO 1133g/10min10
PhysicalSpecific GravityNatural or Representative ColorISO 1183-1,08
